Build Custom Widgets in Magento 2: Complete Development Guide

Creating a custom widget in Magento 2 lets you add dynamic content to CMS pages, blocks, and template files. This guide walks you through building a product slider widget with configurable options that admin users can manage without touching code.

Understanding Magento 2 Widgets

A widget generates dynamic content on your store through a user-friendly admin interface. You can display product listings, affiliate links, third-party content like reviews, or any custom functionality you need.

Magento 2 custom widgets are reusable content blocks configured via the admin panel and rendered on frontend pages. Store administrators can add interactive features to the front-end without programming knowledge.

Widget vs Block: Key Differences

Both serve content management purposes but have distinct roles:

Widgets:

Configurable through admin UI with custom parameters
Placed in multiple page sections via backend
Map to code with parameter sets
Reusable across different pages with varying settings

Blocks:

Static content pieces containing text or child elements
Primarily used by developers in layout XML files
Limited placement options compared to widgets
Can contain widgets (and vice versa)

You can place widgets in various sections across different pages using the backend UI, while static blocks have fewer placement options.

Required Files for Widget Development

File Type	Location / Purpose
module.xml	etc/ - Declares module and dependencies
registration.php	Root directory - Registers module with Magento
widget.xml	etc/ - Defines widget configuration and parameters
Block Class	Block/Widget/ - Handles widget logic and data processing
Template File	view/frontend/templates/widget/ - Renders HTML output
Source Model	Model/Config/Source/ - Provides dropdown options (optional)

Step-by-Step Widget Creation

Configure widget.xml

Define your widget's properties and admin panel parameters:

<?xml version="1.0" ?>

<widgets xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"

xsi:noNamespaceSchemaLocation="urn:magento:module:Magento_Widget:etc/widget.xsd">

<label>Product Slider Widget</label>

<description>Display products based on filters like best sellers, most viewed, or recently added items.</description>

<label translate="true">Title</label>

</parameter>

<label translate="true">Number of Products</label>

</parameter>

<label translate="true">Display Type</label>

</parameter>

</parameters>

</widget>

</widgets>

The id attribute creates a unique widget identifier. The class attribute maps to your block file path.

Build the Block Class

Create the main logic that retrieves and processes data:

<?php

namespace Vendor\Module\Block\Widget;

use Magento\Framework\View\Element\Template;

use Magento\Widget\Block\BlockInterface;

class ProductSlider extends Template implements BlockInterface

{

protected $_template = 'Vendor_Module::widget/product_slider.phtml';

protected $productCollection;

protected $bestSellersFactory;

public function __construct(

Template\Context $context,

\Magento\Catalog\Model\ResourceModel\Product\CollectionFactory $productCollection,

\Magento\Sales\Model\ResourceModel\Report\Bestsellers\CollectionFactory $bestSellersFactory,

array $data = []

) {

$this->productCollection = $productCollection;

$this->bestSellersFactory = $bestSellersFactory;

parent::__construct($context, $data);

}

public function getProductCollection() {

$displayType = $this->getData('display_type');

if ($displayType == "best_sellers") {

return $this->getBestSellers();

} elseif ($displayType == "most_viewed") {

return $this->getMostViewed();

} else {

return $this->getRecentProducts();

}

protected function getBestSellers() {

$collection = $this->productCollection->create();

$collection->addAttributeToSelect('*')

->setPageSize($this->getProductLimit())

->addStoreFilter($this->getStoreId());

return $collection;

}

protected function getProductLimit() {

return (int) $this->getData("product_count");

}

protected function getStoreId() {

return $this->_storeManager->getStore()->getId();

}

The block class must implement BlockInterface. Extend Magento\Framework\View\Element\Template for most widgets.

Create the Template File

Build the HTML structure in view/frontend/templates/widget/product_slider.phtml:

<?php

$products = $block->getProductCollection();

if ($products->getSize() <= 0) { return; }

<h2><?php echo $block->escapeHtml($block->getData("title")); ?></h2>

<?php foreach($products as $product): ?>

<a href="<?php echo $product->getProductUrl(); ?>">

<img src="<?php echo $product->getImage(); ?>" alt="<?php echo $block->escapeHtml($product->getName()); ?>">

<span><?php echo $block->escapeHtml($product->getName()); ?></span>

</a>

</div>

<?php endforeach; ?>

</div>

Add Source Model for Dropdown Options

Create Model/Config/Source/DisplayType.php for select field options:

<?php

namespace Vendor\Module\Model\Config\Source;

class DisplayType implements \Magento\Framework\Data\OptionSourceInterface

{

public function toOptionArray()

{

return [

['value' => 'best_sellers', 'label' => __('Best Selling Products')],

['value' => 'most_viewed', 'label' => __('Most Viewed Products')],

['value' => 'recent_products', 'label' => __('Recently Added Products')]

];

}

Adding Widgets to Your Store

Insert Widget in CMS Pages

Navigate to Content → Pages in admin
Edit or create a page
Click "Insert Widget" in the content editor
Select your custom widget type
Configure parameters (title, product count, display type)
Click "Insert Widget"

Click "Insert Widget"

Add Widget to Static Blocks

Follow the same process in Content → Blocks. Widgets can be added to any CMS block to showcase various content elements.

Insert Widget Programmatically

Add widgets directly in template files:

<?php

echo $this->getLayout()

->createBlock("Vendor\\Module\\Block\\Widget\\ProductSlider")

->setTitle("New Arrivals")

->setProductCount(6)

->setDisplayType("recent_products")

->toHtml();

Built-in Magento Widgets

Magento includes several default widget types for common functionality:

Widget Type	Function
CMS Static Block	Insert existing static blocks into pages
CMS Page Link	Create links to specific CMS pages
Catalog Product Link	Link to individual products
Catalog New Products	Display recently added products
Recently Viewed Products	Show products customers viewed
Recently Compared Products	Display compared products
Orders and Returns	Guest order status checking

Widget Parameter Types

Configure different input types in widget.xml:

text: Single-line text input
textarea: Multi-line text input
select: Dropdown with source model
multiselect: Multiple selection dropdown
block: Block chooser
page_id: CMS page selector
conditions: Product condition builder

Example with multiple parameter types:

<label>Description</label>

</parameter>

<label>Select Categories</label>

</parameter>

Advanced Widget Features

Dependent Parameters

Make parameters conditional based on other selections:

<label>Custom Option</label>

</depends>

</parameter>

The custom_option field only appears when display_type equals "custom".

Widget Caching

Multiple widgets on a page can negatively impact first load performance when not cached. Implement caching in your block class:

protected function _construct()

{

parent::_construct();

$this->addData([

'cache_lifetime' => 86400,

'cache_tags' => ['VENDOR_MODULE_WIDGET'],

]);

}

public function getCacheKeyInfo()

{

return [

'VENDOR_MODULE_WIDGET',

$this->_storeManager->getStore()->getId(),

$this->getData('display_type'),

$this->getData('product_count'),

];

}

Best Practices

Performance Optimization:

Limit product collections with proper page sizes
Add store filters to collections
Implement widget-level caching
Use lazy loading for images

Code Quality:

Follow Magento coding standards
Validate and sanitize admin inputs
Use dependency injection properly
Escape output in templates

User Experience:

Provide clear parameter labels and descriptions
Set sensible default values
Group related parameters logically
Test widgets across different themes

Troubleshooting Common Issues

Widget not appearing:

Clear cache: bin/magento cache:flush
Verify module is enabled
Check widget.xml syntax
Confirm block class path matches widget configuration

Parameters not showing:

Check visible="true" attribute
Verify source model exists for select fields
Review parameter type definitions
Clear configuration cache

Template not rendering:

Confirm template path in block class
Check file permissions
Verify template syntax
Enable developer mode for error details

Conclusion

Developer communities like Magento Stack Exchange offer discussions, insights, and troubleshooting tips for widget development. The official Magento documentation at docs.adobe.com provides comprehensive guides on advanced widget features.

Custom widgets enhance store functionality, improve user experience, and give you control over dynamic content without modifying core files. Start with simple widgets and gradually add complexity as you become comfortable with the architecture.

FAQs

What is a Magento 2 widget?

A Magento 2 widget is a reusable content block that allows you to display dynamic data or features (like products, banners, or forms) on CMS pages, blocks, and layouts without writing code each time.

Why should I create a custom widget in Magento 2?

Building a custom widget lets you add tailored functionality to your store — such as special promotions, custom product sliders, or featured categories — while maintaining full control over its design and behavior.

Where do I define a custom widget in Magento 2?

You define custom widgets in the etc/widget.xml file of your module or theme. This file includes parameters, labels, and block class references that determine how your widget functions and appears.

Which files are essential to create a Magento 2 widget?

Key files include widget.xml for widget configuration, a PHP block class that contains logic, and a .phtml template file that handles frontend rendering.

How do I register a widget in Magento 2?

You register a widget by placing the widget.xml file under your module’s etc/ directory, then running bin/magento setup:upgrade to update the system configuration.

Can I use custom parameters in my widget?

Yes. You can define custom parameters in widget.xml — such as dropdowns, text inputs, or boolean toggles — to allow flexible widget configuration directly from the Magento admin panel.

How do I render a custom widget template?

Reference your template file in the block class using protected $_template, or dynamically load it through layout XML. Ensure the template path matches your theme structure.

What if my widget is not appearing on the frontend?

Check for syntax errors in widget.xml, confirm your block class path, and clear cache using bin/magento cache:flush. Also verify that your module is enabled.

Can I control where my widget appears?

Yes. Widgets can be added to specific CMS pages, static blocks, or layout handles. You can assign display conditions and parameters when inserting the widget through the admin panel.

What’s the best practice for maintaining custom widgets?

Keep widget logic modular in the block class, follow Magento coding standards, use proper namespaces, and document your parameters. Regularly test after version upgrades to ensure compatibility.
